Determination of effective involute parameter limit in generation simulation of gears manufactured by racktype cutters
Istanbul University, Department of Mechanical Engineering,
34320
Istanbul, Turkey
^{*} email: fetvacic@istanbul.edu.tr
Received:
4
October
2016
Accepted:
30
May
2017
This paper studies the computerized tooth profile generation of involute gears cut with racktype cutters. Based on the theory of gearing the mathematical models of generating cutter with asymmetric involute teeth and generated involute gears are given. Beveloid (conical involute) gears are considered for a generalized type of involute gearing for connecting parallel shafts. Effective limits of involute design parameters that determine the actual tip circle radii of the generated gears are investigated. An approach based on contact path of mating gears is proposed to eliminate further operations for standard value of tip circle radius. Computer simulation programs are developed to obtain graphs of generating tools and generated teeth surfaces.
Key words: Beveloid gears / asymmetric involute profile / contact path / generation simulation / effective parameter limit
© AFM, EDP Sciences 2017
1 Introduction
Computer simulation of involute gear generating process has been studied by various authors. A reliable numerical analysis of gear tooth bending or contact stresses for simulating the behavior of gears under working conditions needs precisely determined tooth profile of the machined gear. Therefore, an accurate mathematical model of the gear tooth should be established.
In literature, mathematical modeling of involute gears generated by rack or piniontype cutters have been presented [1–4]. Litvin proposed the Vector Method to develop mathematical models for describing generating and generated teeth surfaces of the various types of gears [4]. This method can also consider functional or productionrequired tooth modifications. Based on Litvin's Vector Method, various authors studied the modeling, undercutting and stress analyzing of conventional and modified gears [5–24].
Vector representation of the generating cutters includes the topland, tip fillet and involute regions. According to the cutter geometry and an appropriate coordinate system, the position vector of generating surface can be expressed. The design parameter of the generating cutter surface which determines the location of points on the related region has upper and lower limits according to the geometry. Then matrix transformation, differential geometry and gear theory are applied to obtain gear tooth surface [4].
In the papers about mathematical modeling of the generating and generated teeth surfaces, the limits of involute region design parameters are given for exact geometry of the cutter but obtained gear teeth profile may extend above the standard tip circle. This fact can be observed in the papers about piniontype generation [6,15,22,23] and racktype generation [5,7,12–14] for example. There should be an effective upper limit of the involute parameter to calculate the exact tip radius of the generated gear. Path of contact for rack and gear may give information about the effective parameter in case of generating with a rack cutter. Thus, without a further CAD operation or an iterative method, the standard tip radius of the involute gear can be obtained.
This paper deals with the determination of the upper limit of the rack cutter's involute region that gives the standard tip circle of the generated gear. The relation between length of path of recess and effective limit is investigated. A general model of involute gears (helical beveloid) is considered for verification and validation of the proposed approach. Beveloid gears can be used in transmissions with intersecting or skewed axes or in transmissions with parallel axes for backlashfree operation. In precision mechanisms gears should be designed to have no backlash [25,26].
The rest of this paper is organized as follows. In the next sections, the mathematical model of the generating cutters is studied. The mathematical models: the locus of the generatingtype cutter surfaces, the equation of meshing and the generated gear tooth surfaces, are given in Sections 2 and 3. Converting to the twodimensional modeling is presented in Section 4. The effective upper limits of involute parameters for racktype generation are presented in Section 5. Computers graphs of generating and generated surfaces are given in Section 6. Results are discussed in Section 7. Finally, a conclusive summary of this study is given in Section 8.
2 Mathematical model of generating cutter
The normal section of a standard rack cutter with a complete generating surface is shown in Figure 1. Regions in the generating surface can be classified as the topland, tip fillet and involute regions. In the case of asymmetric tooth, these regions are designed according to corresponding sides pressure angles.
As shown in Figure 1, regions and of the rack cutter are straight lines that generate different working sides of the involute gears. m_{n} is the normal module of the rack cutter with a asymmetric tooth profile. α_{n1} and α_{n2} are the normal pressure angles. The position vector of regions and are represented in coordinate system S_{n}(X_{n}, Y_{n}, Z_{n}) as follows [13]: (1) (2) where l_{e} and l_{f} are curvilinear parameters of rack cutter surface which determine the location of points on working surface. l_{e} and l_{f} are limited by −h_{a}/cos α_{n1} ≤ l_{e} ≤ h_{t}/cos α_{n1} and −h_{a}/cos α_{n2} ≤ l_{f} ≤ h_{t}/cos α_{n2} for left and rightside of the rack cutter respectively.
To obtain a generalized mathematical model of involute gears, additional coordinate systems should be used and appropriate coordinate transformations between these systems should be applied. In the first step, the rack cutter surface for the helical gear generation is simulated. The normal section of the rack cutter, attached to the coordinate system S_{n}, is translated along the line as shown in Figure 2. Therefore, is also one of the design parameters of the rack cutter surface, and β is the helix angle (RH) of the generated helical gear. The plane Y_{p}Z_{p} can be regarded as the pitch plane of the rack cutter [7]. The coordinate transformation matrix from coordinate system S_{n} to S_{p} can be written as follows: (3)
In the second step, the taper hobbing process is simulated. The generating cutter is inclined to the gear axis by the cone angle δ as shown in Figure 3. As a result, the rack cutter is represented in the plane axode coordinate system S_{c}(X_{c}, Y_{c}, Z_{c}) [7]. The coordinate transformation matrix from coordinate system S_{p} to S_{c} can be written as follows: (4)
The position vector of generating cutter represented in coordinate system S_{c}(X_{c}, Y_{c}, Z_{c})can be written as follows: (5) where superscript i represents regions , , , , and . We can write down the equations of generating surface in open form as follows: (6)
Tangent plane or tangent vectors determine the existence of regular surfaces. The tangent plane of the generating cutter surface is composed of two vectors: ∂R_{c}/∂l_{j} and ∂R_{c}/∂λ (partial derivatives). Surface normal is given by the cross product of the partial derivatives. According to differential geometry and gear theory, normal vectors of regions of the rack cutter surface can be represented in coordinate system S_{c} by the following equation [4]. (7)
The unit normal vector of the rack cutter surface is represented by equation (8) [4]. (8)
Fig. 1
The normal section of the rack cutter.
Fig. 2
Formation of rack cutter surface for helical gear generation.
Fig. 3
Formation of rack cutter surface for beveloid gear generation.
3 Mathematical model of generated gear
Figure 4 depicts the coordinate relationship between the rack cutter and the generated gear. Coordinate system S_{h}(X_{h}, Y_{h}, Z_{h}) represents the fixed coordinate system. S_{c}(X_{c}, Y_{c}, Z_{c}) is the plane axode coordinate system attached to the rack cutter and coordinate system S_{1} (X_{1}, Y_{1}, Z_{1}) is attached to the generated gear [7]. While the gear blank rotates through an angle φ_{1}, the rack cutter translates the linear displacement S = r_{p1}φ_{1} along Y_{c} axis. Therefore, the coordinate transformation matrix from S_{c} to S_{1} can be described as [4]: (9)
Fundamental law of gearing states that the common normal to the transverse section of the cutter and the gear tooth surface must pass through the instantaneous center of rotation (pitch point). Therefore, the equation meshing can be represented using coordinate system S_{c}(X_{c}, Y_{c}, Z_{c}) as follows [4]: (10) where , and are the coordinates of a point on the instantaneous axis of gear rotation I–I represented in coordinate system S_{c}; , and are the surface coordinates of the rack cutter; symbols , and symbolize the components of the common unit normal represented in coordinate system S_{c}.
According to the theory of gearing [4], the mathematical model of the generated gear tooth surface is a combination of the meshing equation and the locus (family) of the rack cutter surfaces. The locus of the cutter surface, expressed in coordinate system S_{1}, can be determined as follows [4]: (11)
As a result, the mathematical model of the gear tooth surfaces can be obtained by simultaneously considering equations (11) and (10).
Helical beveloid gear is the generalized model of the involute gears mounted on parallel axes. Straight conical involute gears, helical gears and spur gears can be represented by the equations by letting the helix angle, the cone angle, or both be equal to zero [10].
Fig. 4
Coordinate relationship between rack cutter and generated gear.
4 Tooth profile analysis on the plane of rotation
In beveloid gears profile shift varies along the facewidth. As a result the tooth geometry changes across the facewidth. Moreover helix angle also alters the geometry. Contact path, zero topland and undercutting should be investigated in several transverse planes. To express the profile of the imaginary rack cutter on the plane of rotation Y_{c}Z_{c}, the third item of equation (6) can be adopted as follows: (12)
Considering the first two items of equation (6) together with equation (12), the profile of the twodimensional rack cutter can be obtained and expressed on the plane of rotation by treating z_{c} as a constant. An important macrogeometric property of helical beveloid gear is the different transverse pressure angles on left and right sides that results asymmetric teeth profiles [7,10,25,27]. Transverse pressure angles are formulated in equations (13) and (14). (13) (14)
5 Contact path and determination of effective parameter limit
Figure 5 depicts the line of action in meshing of the rack cutter and the helical gear being generated at a transverse section. The upper end of path of contact is point T where the tip circle of the pinion intersects the line of action. is the length of path of recess. From the gear geometry, can be calculated as where r_{b} is the base circle radius of the generated gear and α_{t} is the transverse pressure angle. Therefore, the effective upper limit of the involute parameter is calculated as . As a result, when calculating the generated profile we should use −h_{a}/cos α_{n1} ≤ l_{e} ≤ h_{eff}/cos α_{n1} instead of −h_{a}/cos α_{n1} ≤ l_{e} ≤ h_{t}/cos α_{n1}.
The equation of effective limit can also be extended for beveloid gears. We can write for a transverse section z_{c} along the face width of a beveloid gear. The pressure angles on plane of rotation can be calculated as tan α_{t} = tan α_{n} cos δ for straight beveloid and tan α_{t} = ∓ tan β sin δ + tan α_{n} cos δ sec β for helical beveloid tooth where δ is the cone angle and β is the helix angle.
Fig. 5
Meshing diagram of a rack cutter and pinion.
6 Computer applications
Based on the mathematical models given in previous sections, computer programs can be developed to obtain the coordinates of the generating cutters and generated gears. In this study the program is written with GWBASIC. Output of files is evaluated with GRAPHER to obtain computer graphs.
Figure 6 displays a transverse section of a helical gear with symmetric involute teeth. In this example, design parameters are selected as: normal module m_{n} = 5 mm, normal pressure angle α_{n1} = 20°, helix angle β = 15° and number of teeth T = 13. The proposed limit of the design parameter gives the exact length of involute profile that is limited by standard tip circle radius of the workpiece.
Figure 7 displays a transverse section of a straight beveloid gear. In this example, design parameters are selected as: normal module m_{n} = 5 mm, normal pressure angle α_{n1} = 20°, cone angle δ = 15°, number of teeth T = 25 and with a crosssection constraint z_{c} = − 10 mm. A negative profile shift coefficient appears near the heel so undercutting is observed. Transverse pressure angle is calculated as α_{t} = 19.37°.
Figure 8 displays a transverse section of a helical beveloid gear. In this example, design parameters are selected as: normal module m_{n} = 5 mm, normal pressure angle α_{n1} = 20°, helix angle β = 15°, cone angle δ = 15°, number of teeth T = 25 and with a crosssection constraint z_{c} = 0. Asymmetric tooth profile on the plane of rotation is observed. Transverse pressure angles on the left and right sides are α_{t1} = 16.41602° and α_{t2} = 23.42808°, respectively. Selected parameters in this example produces the left side profile be on the undercutting limit. As the conventional involute parameter limit is used on the left side, it gives extended involute profile above the standard tip circle.
Figure 9 displays a transverse section of a helical beveloid gear cut by a rack cutter with asymmetric teeth. Also relative positions of the generating cutter with respect to gear blank during generation process are illustrated. Design parameters are selected as: normal module m_{n} = 5 mm, left side normal pressure angle α_{n1} = 26.68735°, right side normal pressure angle α_{n2} = 20°, helix angle β = 15°, cone angle δ = 15°, number of teeth T = 25 and with a crosssection constraint z_{c} = 0. Transverse pressure angles are calculated as α_{t1} = 23.42808° and α_{t2} = 23.42808° for left and right sides, respectively. Therefore a symmetric profile on the plane of rotation can be obtained.
Fig. 6
Helical gear tooth profile.
Fig. 7
Straight beveloid gear tooth profile.
Fig. 8
Helical beveloid gear tooth profile.
Fig. 9
Helical beveloid gear generated by an asymmetric cutter.
7 Results
Generatingtype cutters are widely used in mass production of gears. In literature most of studies about mathematical modeling and analysis of gears are based on Litvin's vector approach [4]. This approach begins with the parametric representation of tool surface in vector form. As the tool surface is composed of different regions, the intervals of curvilinear parameters that determine the position of a point in the region should maintain position, tangent, or curvature continuity of adjacent regions. This study presents an effective upper limit of involute parameter that gives the exact length of generated involute profile. As stated in Section 5, from the contact path of rack and gear mechanism radial distance from pitch point to the end point of contact can be defined as effective upper limit of involute parameter. This limit depends on the transverse section through the face width. Proposed formula is derived for generalized model of involute gears mounted on parallel axis.
In Section 6, illustrative examples are given. In Figures 6–8, the proposed upper limit of involute parameter is used for generated profile on the right side. On the left side, generated involute profile ends beyond the actual tip circle radius of the gear blank. The extended part should be trimmed.
Beveloid gears can be considered as involute gears with a linear variable profile shift along the face width. As the profile shift changes from a negative value to a positive value, undercutting and zero topland can be observed in several transverse sections of generated gear. Moreover, helix angle causes asymmetric profile on the plane of rotation. Figure 8 displays transverse section of a helical beveloid gear that has different pressure angle on left and right sides. As the transverse pressure angle decreases the risk of undercutting increases. To prevent undercutting in helical beveloid gears rack cutter with asymmetric involute teeth can be used. Figure 9 displays helical beveloid gear generated by a rack cutter with an asymmetric tooth flank.
The author used the locus equation of the cutter and obtained illustrations displaying relative positions of the cutter during generation by manipulating rolling parameter as −π/4 ≤ φ_{1} ≤ π/4 in the developed code. An example is illustrated in Figure 9. It has been reported in literature that the relative positions provide a basis to determine the chip geometry [28].
Like as in manufacturing cylindrical involute gears, hobbing tools are used for beveloid gearing. Conventional gear hobbing machines are arranged with the methods proposed by Mitome [27]. They are the inclinedworkarbor taper hobbing method and the tablesliding taper hobbing method. Also generating grinding wheels can be used. Hobbing or grinding is simulated by an imaginary rack cutter in computer applications.
The coordinates of the points on the gear tooth can also be imported into a CAD software to obtain 3D models of gears for 3D Printing. Then it is exported to 3D Printing Machines where physical model of gears can be obtained. Figure 10 displays a solid model of a straight beveloid gear. In this study, prototypes of straight beveloid gears are also manufactured by a 3D printer that runs on fused deposition modeling (FDM) technology. Figure 11 displays straight beveloid gears made from polylactide (PLA).
Fig. 10
Solid model of a straight beveloid gear.
Fig. 11
3D printed straight beveloid gears.
8 Conclusions
Generatingtype of cutters is widely used in mass production of involute gears. In this study, mathematical models of rack cutters and beveloid gears are given, taking into account the asymmetric involute tooth profile. In the open literature obtained gear teeth involute profile may extend above the standard tip circle when using upper limit of involute parameter for the profile of cutter. Major finding in this paper is the concept of analytically derived effective upper limit of involute parameter. This approach eliminates CAD operations or iterative methods needed to correct the involute profile exceeding the limit that occurs when using design parameters in the conventional range. Examples for different cases are presented to validate the proposed approach.
Undercutting and zero topland should be checked in beveloid gears due to varying profile shift from toe to heel. For helical beveloid gears cutters with asymmetric involute teeth can be used to prevent the undercutting on the related side.
The relative positions of the generating cutter can also be illustrated. Chip geometry can be described from the relative positions. The description of chip geometry can be used predicting the tool life and cutting forces for manufacturing in further studies.
In addition to hobbing and grinding, the additive manufacturing methods (3D printing) can also be used for producing beveloid gears. The mathematical model given in this study can also be used to obtain 3D models in a CAD software. 3D CAD models can be obtained from several transverse sections by using extrude/sweep operations.
Beveloid gears have found wide application in marine transmission and automotive industry. Beveloid gearing is a cheaper means of limiting backlash in precision mechanisms such as industrial robots. In further studies based on beveloid gears, mechanical aspects such as friction and wear can be considered. A wearmodified model proposed by Brauer and Andersson can be extended to helical beveloid gears [26]. Modifications such as tip chamfering, parabolic tooth and root freecut can be applied to the mathematical model of generating cutter. These aspects are beyond to the scope of this study.
Nomenclature
b_{c}: tool setting of the rack cutter
h_{a}: tool setting of the rack cutter
h_{t}: tool setting of the rack cutter
l_{j}: curvilinear coordinates of rack cutter where subscript j = a, b, c, d, e, f
[M_{1c}]: coordinate transformation matrix from coordinate system S_{c} to S_{1}
n_{c}: unit normal vector of rack cutter surface
: position vector rack cutter surface for gear generation
: position vector of rack cutter normal section where superscript i represents regions , , , , and of the rack cutter surface
: the family of the rack cutter surfaces
r_{b}: radius of base circle of generated gear
r_{p1}: radius of pitch circle of generated gear
r_{t}: radius of tip circle of generated gear
S_{c}: rack cutter coordinate system
S_{f}: fixed coordinate system
S_{1}: gear blank coordinate system
T: number of teeth of generated gear
α_{n1}: normal pressure angle of the rack cutter (left side)
α_{n2}: normal pressure angle of the rack cutter (right side)
α_{t}: transverse pressure angle
ρ_{1}: left tip fillet radius of the cutter
ρ_{2}: right tip fillet radius of the cutter
References
 E. Buckingham, Analytical mechanics of gears, McGrawHill, New York, 1988 [Google Scholar]
 C. Salamoun, M. Suchy, Computation of helical or spur gear fillets, Mech. Mach. Theory 8 (1973) 305–323 [CrossRef] [Google Scholar]
 J.R. Colbourne, The geometry of involute gears, SpringerVerlag, New York, 1987 [CrossRef] [Google Scholar]
 F.L. Litvin, Gear geometry and applied theory, PrenticeHall, New Jersey, 1994 [Google Scholar]
 C.B. Tsay, Helical gears with involute shaped teeth: geometry, computer simulation, tooth contact analysis and stress analysis, J. Mech. Des. 110 (1988) 482–491 [Google Scholar]
 S.L. Chang, C.B. Tsay, Computerized tooth profile generation and undercut analysis of noncircular gears manufactured with shaper cutters, J. Mech. Des. 120 (1998) 92–99 [CrossRef] [Google Scholar]
 C.C. Liu, C.B. Tsay, Tooth undercutting of beveloid gears, J. Mech. Des. 123 (2001) 569–576 [CrossRef] [Google Scholar]
 C.C. Liu, C.B. Tsay, Mathematical models and contact simulations of concave beveloid gears, J. Mech. Des. 124 (2002) 753–760 [CrossRef] [Google Scholar]
 G. Figliolini, J. Angeles, The synthesis of elliptical gears generated by shapercutters, J. Mech. Des. 125 (2003) 793–801 [CrossRef] [Google Scholar]
 J. Brauer, A general finite element model of involute gears, Finite Elem. Anal. Des. 40 (2004) 1857–1872 [CrossRef] [Google Scholar]
 K.J. Huang, H.W. Su, Approaches to parametric element constructions and dynamic analyses of spur/helical gears including modifications and undercutting, Finite Elem. Anal. Des. 46 (2010) 1106–1113 [CrossRef] [Google Scholar]
 C.F. Chen, C.B. Tsay, Tooth profile design for the manufacture of helical gear sets with small numbers of teeth, Int. J. Mach. Tool Manuf. 45 (2005) 1531–1541 [CrossRef] [Google Scholar]
 S.C. Yang, Mathematical model of a helical gear with asymmetric involute teeth and its analysis, Int. J. Adv. Manuf. Technol. 26 (2005) 448–456 [CrossRef] [Google Scholar]
 S.C. Yang, Study on an internal gear with asymmetric involute teeth, Mech. Mach. Theory 42 (2006) 977–994 [CrossRef] [Google Scholar]
 M.F. Tsay, Z.H. Fong, Novel profile modification methodology for moulded facegear drives, J. Mech. Eng. Sci. 221 (2007) 715–725 [CrossRef] [Google Scholar]
 S.Z. Wu, S.J. Tsai, Contact stress analysis of skew conical involute gear drives in approximate line contact, Mech. Mach. Theory 44 (2009) 1658–1676 [CrossRef] [Google Scholar]
 C. Fetvaci, Computer simulation of helical gears with asymmetric involute teeth, J. Fac. Eng. Archit. Gazi Univ. 25 (2010) 441–447 [Google Scholar]
 C. Fetvaci, Generation simulation of involute spur gears machined by piniontype shaper cutters, Stroj. Vestn. – J. Mech. Eng. 56 (2010) 644–652 [Google Scholar]
 W.L. Chen, C.B. Tsay, Mathematical model and tooth surfaces of recess action worm gears with doubledepth teeth, Mech. Mach. Theory 46 (2011) 1840–1853 [CrossRef] [Google Scholar]
 Y.C. Chen, C.B. Tsay, Stress analysis of a helical gear set with localized bearing contact, Finite Elem. Anal. Des. 38 (2002) 707–723 [CrossRef] [Google Scholar]
 J.H. Kuang, W.L. Chen, Determination of tip parameters for the protuberance preshaving cutters, Mech. Mach. Theory 31 (1996) 839–849 [CrossRef] [Google Scholar]
 C.B. Tsay, W.Y. Liu, Y.C. Chen, Spur gear generation by shaper cutters, J. Mater. Process. Technol. 104 (2000) 271–279 [CrossRef] [Google Scholar]
 C. Fetvaci, Computer simulation of involute tooth generation, in: M. Gokcek (Ed.), Mechanical engineering, InTech, Rijeka, Croatia, 2012, pp. 503–526 [Google Scholar]
 C. Fetvaci, Computer simulation of helical gears generated by racktype cutters, Arab. J. Sci. Eng. 36 (2011) 1321–1332 [CrossRef] [Google Scholar]
 J. Börner, K. Humm, F. Joachim, Development of conical involute gears (beveloids) for vehicle transmission, Gear Technol. 22(6) (2005) 28–35 [Google Scholar]
 J. Brauer, S. Andersson, Simulation of wear in gears with flank interference − a mixed FE and analytical approach, Wear 254 (2003) 1216–1232 [CrossRef] [Google Scholar]
 K. Mitome, Conical involute gear, part 1: design and production system, Bull. JSME 26(212) (1983) 299–305 [CrossRef] [Google Scholar]
 K.D. Bouzakis, S. Kombogiannis, A. Antoniadis, N. Vidakis, Gear hobbing cutting process simulation and tool wear prediction models, J. Manuf. Sci. Eng. 124 (2002) 42–51 [CrossRef] [Google Scholar]
